Dexible Hacking Analysis

Dexible

개요

해당 포스트는 2023년 1월 27일 Dexible에서 일어난 약 1,540,000 달러의 해킹 사건을 분석한 포스트입니다.

컨트랙트 취약점과 해킹 기법, 취약점 수정에 초점을 맞추어 포스트를 작성하였습니다.



취약한 컨트랙트

해킹 대상이 된 컨트랙트는 Dexible로 링크를 통해 확인할 수 있습니다.

취약점을 찾기 위해서는 두 개의 컨트랙트(Dexible.sol, SwapHandler.sol)를 보아야 합니다.

//SPDX-License-Identifier: Unlicense
pragma solidity ^0.8.17;

import "./interfaces/IDexible.sol";
import "./baseContracts/DexibleView.sol";
import "./baseContracts/SwapHandler.sol";
import "./baseContracts/ConfigBase.sol";

contract Dexible is DexibleView, ConfigBase, SwapHandler, IDexible {

    event ReceivedFunds(address from, uint amount);
    event WithdrewETH(address indexed admin, uint amount);

    /*
    constructor(DexibleStorage.DexibleConfig memory config) {
        configure(config);
    }
    */
    function initialize(DexibleStorage.DexibleConfig calldata config) public {
        configure(config);
    }

    receive() external payable {
       emit ReceivedFunds(msg.sender, msg.value);
    }

    function swap(SwapTypes.SwapRequest calldata request) external onlyRelay notPaused {
        //compute how much gas we have at the outset, plus some gas for loading contract, etc.
        uint startGas = gasleft();
        SwapMeta memory details = SwapMeta({
            feeIsInput: false,
            isSelfSwap: false,
            startGas: startGas,
            preSwapVault: address(DexibleStorage.load().communityVault),
            bpsAmount: 0,
            gasAmount: 0,
            nativeGasAmount: 0,
            toProtocol: 0,
            toRevshare: 0,
            outToTrader: 0,
            preDXBLBalance: 0,
            outAmount: 0,
            inputAmountDue: 0
        });

        bool success = false;
        //execute the swap but catch any problem
        try this.fill{
            gas: gasleft() - 80_000
        }(request, details) returns (SwapMeta memory sd) {
            details = sd;
            success = true;
        } catch {
            console.log("Swap failed");
            success = false;
        }

        postFill(request, details, success);
    }

    function selfSwap(SwapTypes.SelfSwap calldata request) external notPaused {
        //we create a swap request that has no affiliate attached and thus no
        //automatic discount.
        SwapTypes.SwapRequest memory swapReq = SwapTypes.SwapRequest({
            executionRequest: ExecutionTypes.ExecutionRequest({
                fee: ExecutionTypes.FeeDetails({
                    feeToken: request.feeToken,
                    affiliate: address(0),
                    affiliatePortion: 0
                }),
                requester: msg.sender
            }),
            tokenIn: request.tokenIn,
            tokenOut: request.tokenOut,
            routes: request.routes
        });
        SwapMeta memory details = SwapMeta({
            feeIsInput: false,
            isSelfSwap: true,
            startGas: 0,
            preSwapVault: address(DexibleStorage.load().communityVault),
            bpsAmount: 0,
            gasAmount: 0,
            nativeGasAmount: 0,
            toProtocol: 0,
            toRevshare: 0,
            outToTrader: 0,
            preDXBLBalance: 0,
            outAmount: 0,
            inputAmountDue: 0
        });
        details = this.fill(swapReq, details);
        postFill(swapReq, details, true);
    }

    function withdraw(uint amount) public onlyAdmin {
        address payable rec = payable(msg.sender);
        require(rec.send(amount), "Transfer failed");
        emit WithdrewETH(msg.sender, amount);
    }
}

Dexible.sol

//SPDX-License-Identifier: Unlicense
pragma solidity ^0.8.17;

import "../interfaces/ISwapHandler.sol";
import "../DexibleStorage.sol";
import "./AdminBase.sol";
import "../../vault/interfaces/ICommunityVault.sol";
import "../LibFees.sol";

import "hardhat/console.sol";

import "@openzeppelin/contracts/token/ERC20/utils/SafeERC20.sol";
import "@openzeppelin/contracts/utils/Strings.sol";

abstract contract SwapHandler is AdminBase, ISwapHandler {

    using SafeERC20 for IERC20;

    struct SwapMeta {
        bool feeIsInput;
        bool isSelfSwap;
        //if a migration occurs during a swap, we don't want to charge
        //the trader for the txn if possible
        address preSwapVault;
        uint startGas;
        uint toProtocol;
        uint toRevshare;
        uint outToTrader;
        uint outAmount;
        uint bpsAmount;
        uint gasAmount;
        uint nativeGasAmount;
        uint preDXBLBalance;
        uint inputAmountDue;
    }


    function fill(SwapTypes.SwapRequest calldata request, SwapMeta memory meta) external onlySelf returns (SwapMeta memory)  {

        preCheck(request, meta);
        meta.outAmount = request.tokenOut.token.balanceOf(address(this));

        for(uint i=0;i<request.routes.length;++i) {
            SwapTypes.RouterRequest calldata rr = request.routes[i];
            IERC20(rr.routeAmount.token).safeApprove(rr.spender, rr.routeAmount.amount);
            (bool s, ) = rr.router.call(rr.routerData);

            if(!s) {
                revert("Failed to swap");
            }
        }
        uint out = request.tokenOut.token.balanceOf(address(this));
        if(meta.outAmount < out) {
            meta.outAmount = out - meta.outAmount;
        } else {
            meta.outAmount = 0;
        }

        console.log("Expected", request.tokenOut.amount, "Received", meta.outAmount);
        //first, make sure enough output was generated
        require(meta.outAmount >= request.tokenOut.amount, "Insufficient output generated");
        return meta;
    }

    function postFill(SwapTypes.SwapRequest memory request, SwapMeta memory meta, bool success) internal  {

        if(success) {
            //if we succeeded, then do successful post-swap ops
            handleSwapSuccess(request, meta);
        }  else {
            //otherwise, handle as a failure
            handleSwapFailure(request, meta);
        }
        //pay the relayer their gas fee if we have funds for it
        payRelayGas(meta.nativeGasAmount);
    }

    /**
     * When a relay-based swap fails, we need to account for failure gas fees if the input
     * token is the fee token. That's what this function does
     */
    function handleSwapFailure(SwapTypes.SwapRequest memory request, SwapMeta memory meta) internal {

        DexibleStorage.DexibleData storage dd = DexibleStorage.load();
        uint gasInFeeToken = 0;
        if(meta.feeIsInput) {
            unchecked {
                //the total gas used thus far plus some post-op stuff that needs to get done
                uint totalGas = (meta.startGas - gasleft());

                console.log("Estimated gas used for failed gas payment", totalGas);
                meta.nativeGasAmount = LibFees.computeGasCost(totalGas, false);
            }

            gasInFeeToken = dd.communityVault.convertGasToFeeToken(address(request.executionRequest.fee.feeToken), meta.nativeGasAmount);

            //console.log("Transferring partial input token to devteam for failure gas fees");

            //console.log("Failed gas fee", gasInFeeToken);

            //transfer input assets from trader to treasury. Recall that any previous transfer amount
            //to this contract was rolled back on failure, so we transfer the funds for gas only
            request.executionRequest.fee.feeToken.safeTransferFrom(request.executionRequest.requester, dd.treasury, gasInFeeToken);
        }

        emit SwapFailed(request.executionRequest.requester, address(request.executionRequest.fee.feeToken), gasInFeeToken);
    }

    /**
     * This is called when a relay-based swap is successful. It basically rewards DXBL tokens
     * to trader and pays appropriate fees.
     */
    function handleSwapSuccess(SwapTypes.SwapRequest memory request,
                SwapMeta memory meta) internal {

        //reward trader with DXBL tokens
        collectDXBL(request, meta.feeIsInput, meta.outAmount);

        //pay fees
        payAndDistribute(request, meta);
    }

    /**
     * Reward DXBL to the trader
     */
    function collectDXBL(SwapTypes.SwapRequest memory request, bool feeIsInput, uint outAmount) internal {
        DexibleStorage.DexibleData storage dd = DexibleStorage.load();

        uint value = 0;
        if(feeIsInput) {
            //when input, the total input amount is used to determine reward rate
            value = request.tokenIn.amount;
        } else {
            //otherwise, it's the output generated from the swap
            value = outAmount;
        }
        //Dexible is the only one allowed to ask the vault to mint tokens on behalf of a trader
        //See RevshareVault for logic of minting rewards

        //NOTE: a migration to a new vault could occur as part of this call. It would just
        //change the address of the vault in storage and all proceeds would be forwarded to
        //the new vault address. All minting occurs before the migration so mint rates and
        //token balances are all forwarded to the new vault as part of the migration. It is
        //possible, however, that gas estimates would not account for the migration.
        dd.communityVault.rewardTrader(request.executionRequest.requester, address(request.executionRequest.fee.feeToken), value);
    }


    /**
     * Distribute payments to revshare pool, affiliates, treasury, and trader
     */
    function payAndDistribute(SwapTypes.SwapRequest memory request,
                                SwapMeta memory meta) internal  {
        allocateRevshareAndAffiliate(request, meta);
        payProtocolAndTrader(request, meta);
    }

    /**
     * Allocate bps portions to revshare pool and any associated affiliate
     */
    function allocateRevshareAndAffiliate(SwapTypes.SwapRequest memory request,
                                SwapMeta memory meta) internal view {

        DexibleStorage.DexibleData storage dd = DexibleStorage.load();

        //assume trader gets all output
        meta.outToTrader = meta.outAmount;

        //the bps portion of fee.
        meta.bpsAmount = computeBpsFee(request, meta.feeIsInput, meta.preDXBLBalance, meta.outAmount);

        //console.log("Total bps fee", payments.bpsAmount);
        uint minFee = LibFees.computeMinFeeUnits(address(request.executionRequest.fee.feeToken));
        if(minFee > meta.bpsAmount) {
            //console.log("Trade too small. Charging minimum flat fee", minFee);
            meta.bpsAmount = minFee;
        }

        //revshare pool gets portion of bps fee collected
        meta.toRevshare = (meta.bpsAmount * dd.revshareSplitRatio) / 100;

        //console.log("To revshare", meta.toRevshare);

        //protocol gets remaining bps but affiliate fees come out of its portion. Will revert if
        //Dexible miscalculated the affiliate reward portion. However, the call would revert here and
        //Dexible relay would pay the gas fee for its mistake. Self-swap has no affiliate so no revert
        //would happen.
        require(request.executionRequest.fee.affiliatePortion < meta.bpsAmount-meta.toRevshare, "Miscalculated affiliate portion");
        meta.toProtocol = (meta.bpsAmount-meta.toRevshare) - request.executionRequest.fee.affiliatePortion;

        //console.log("Protocol pre-gas", meta.toProtocol);

        //fees accounted for thus far
        uint total = meta.toRevshare + meta.toProtocol + request.executionRequest.fee.affiliatePortion;

        if(!meta.feeIsInput) {
            //this is an interim calculation. Gas fees get deducted later as well. This will
            //also revert if insufficient output was generated to cover all fees
            //console.log("Out amount", meta.outAmount, "Total fees so far", total);
            if(meta.outAmount < total) {
                revert(
                    string(
                        abi.encodePacked(
                            _concatUintString("Insufficient output to pay bps fees. Required: ", total),
                            _concatUintString(" Output amount: ", meta.outAmount)
                        )
                    )
                );
            }
            meta.outToTrader = meta.outAmount - total;
        } else {
            //input debits are handled later so we keep track of what's due so far in bps fees
            meta.inputAmountDue = total;
        }
    }

    /**
     * Final step to compute gas consumption for trader and pay the vault, protocol, affiliate, and trader
     * their portions.
     */
    function payProtocolAndTrader(SwapTypes.SwapRequest memory request,
                            SwapMeta memory meta) internal {

        DexibleStorage.DexibleData storage dd = DexibleStorage.load();

        if(!meta.isSelfSwap) {
            //If this was a relay-based swap, we need to pay treasury an estimated gas fee

            //we leave unguarded for gas savings since we know start gas is always higher
            //than used and will never rollover without costing an extremely large amount of $$
            unchecked {
                //console.log("Start gas", meta.startGas, "Left", gasleft());

                //the total gas used thus far plus some post-op buffer for transfers and events
                uint totalGas = (meta.startGas - gasleft());
                if(address(dd.communityVault) != meta.preSwapVault && totalGas > 200_000) {
                    totalGas -= 200_000; //give credit for estimated migration gas
                }

                console.log("Estimated gas used for trader gas payment", totalGas);
                meta.nativeGasAmount = LibFees.computeGasCost(totalGas, true); //(totalGas * tx.gasprice);
            }
            //use price oracle in vault to get native price in fee token
            meta.gasAmount = dd.communityVault.convertGasToFeeToken(address(request.executionRequest.fee.feeToken), meta.nativeGasAmount);
            //console.log("Gas paid by trader in fee token", meta.gasAmount);

            //add gas payment to treasury portion
            meta.toProtocol += meta.gasAmount;
            //console.log("Payment to protocol", meta.toProtocol);

            if(!meta.feeIsInput) {
                //if output was fee, deduct gas payment from proceeds, revert if there isn't enough output
                //for it (should have been caught offchain before submit). We make sure the trader gets
                //something out of the deal by ensuring output is more than gas.
                if(meta.outToTrader <= meta.gasAmount) {
                    revert(
                        string(
                            abi.encodePacked(
                                _concatUintString("Insufficient output to pay gas fees. Required: ", meta.gasAmount),
                                _concatUintString(" Trader output proceeds: ", meta.outToTrader)
                            )
                        )
                    );
                }
                meta.outToTrader -= meta.gasAmount;
            } else {
                //other make sure it's account for as input debit
                meta.inputAmountDue += meta.gasAmount;
            }
            //console.log("Proceeds to trader", payments.outToTrader);
        }

        //now distribute fees
        IERC20 feeToken = request.executionRequest.fee.feeToken;
        if(meta.feeIsInput) {
            //make sure we didn't overspend on trading input amount and not have enough to cover
            //fees
            uint totalInputSpent = request.routes[0].routeAmount.amount + meta.inputAmountDue;
            //console.log("Total input spent", totalInputSpent, "Expected input amount", request.tokenIn.amount);
            if(totalInputSpent > request.tokenIn.amount) {
                revert(
                    string(
                        abi.encodePacked(_concatUintString("Attempt to spend more input than anticipated. Total required: ", totalInputSpent),
                                        _concatUintString(" Max input: ", request.tokenIn.amount))
                    )
                );
            }
            //pay protocol from input token
            feeToken.safeTransferFrom(request.executionRequest.requester, dd.treasury, meta.toProtocol);

            //pay vault from input token
            feeToken.safeTransferFrom(request.executionRequest.requester, address(dd.communityVault), meta.toRevshare);
            if(request.executionRequest.fee.affiliatePortion > 0) {
                //pay affiliate their portion which was deducted from protocol's bps portion
                feeToken.safeTransferFrom(request.executionRequest.requester, request.executionRequest.fee.affiliate, request.executionRequest.fee.affiliatePortion);
                emit AffiliatePaid(request.executionRequest.fee.affiliate, address(feeToken), request.executionRequest.fee.affiliatePortion);
            }
        } else {
            //otherwise, transfer directly from generated output
            //console.log("Total output spent", (meta.toProtocol + meta.toRevshare + request.executionRequest.fee.affiliatePortion));
            //console.log("Total output generated", meta.outAmount);
            feeToken.safeTransfer(dd.treasury, meta.toProtocol);
            feeToken.safeTransfer(address(dd.communityVault), meta.toRevshare);
            if(request.executionRequest.fee.affiliatePortion > 0) {
                //pay affiliate their portion
                feeToken.safeTransfer(request.executionRequest.fee.affiliate, request.executionRequest.fee.affiliatePortion);
                emit AffiliatePaid(request.executionRequest.fee.affiliate, address(feeToken), request.executionRequest.fee.affiliatePortion);
            }
        }

        //and send trader their proceeds
        request.tokenOut.token.safeTransfer(request.executionRequest.requester, meta.outToTrader);

        emit SwapSuccess(request.executionRequest.requester,
                    request.executionRequest.fee.affiliate,
                    request.tokenOut.amount,
                    meta.outToTrader,
                    address(request.executionRequest.fee.feeToken),
                    meta.gasAmount,
                    request.executionRequest.fee.affiliatePortion,
                    meta.bpsAmount);
    }

    function preCheck(SwapTypes.SwapRequest calldata request, SwapMeta memory meta) internal {
        //make sure fee token is allowed
        address fToken = address(request.executionRequest.fee.feeToken);
        DexibleStorage.DexibleData storage dd = DexibleStorage.load();
        require(
            dd.communityVault.isFeeTokenAllowed(fToken),
            "Fee token is not allowed"
        );

        //and that it's one of the tokens swapped
        require(fToken == address(request.tokenIn.token) ||
                fToken == address(request.tokenOut.token),
                "Fee token must be input or output token");

         //get the current DXBL balance at the start to apply discounts
        meta.preDXBLBalance = dd.dxblToken.balanceOf(request.executionRequest.requester);

        //flag whether the input token is the fee token
        meta.feeIsInput = address(request.tokenIn.token) == address(request.executionRequest.fee.feeToken);

        //transfer input tokens for router so it can perform swap
        //console.log("Transfering input for trading:", request.routes[0].routeAmount.amount);
        request.tokenIn.token.safeTransferFrom(request.executionRequest.requester, address(this), request.routes[0].routeAmount.amount);
        //console.log("Expected output", request.tokenOut.amount);
    }


    /**
     * Pay the relay with gas funds stored in this contract. The gas used provided
     * does not include arbitrum multiplier but may include additional amount for post-op
     * gas estimates.
     */
    function payRelayGas(uint gasFee) internal {
        if(gasFee == 0) {
            return;
        }

        //console.log("Relay Gas Reimbursement", gasFee);
        //if there is ETH in the contract, reimburse the relay that called the fill function
        if(address(this).balance < gasFee) {
            //console.log("Cannot reimburse relay since do not have enough funds");
            emit InsufficientGasFunds(msg.sender, gasFee);
        } else {
            //console.log("Transfering gas fee to relay");
            payable(msg.sender).transfer(gasFee);
            emit PaidGasFunds(msg.sender, gasFee);
        }
    }

    /**
     * Compute the bps to charge for the swap. This leverages the DXBL token to compute discounts
     * based on trader balances and discount rates applied per DXBL token.
     */
    function computeBpsFee(SwapTypes.SwapRequest memory request, bool feeIsInput, uint preDXBL, uint outAmount) internal view returns (uint) {
        //apply any discounts
        DexibleStorage.DexibleData storage ds = DexibleStorage.load();

        return ds.dxblToken.computeDiscountedFee(
            IDXBL.FeeRequest({
                trader: request.executionRequest.requester,
                amt: feeIsInput ? request.tokenIn.amount : outAmount,
                referred: request.executionRequest.fee.affiliate != address(0),
                dxblBalance: preDXBL,
                stdBpsRate: ds.stdBpsRate,
                minBpsRate: ds.minBpsRate
            }));
    }

    function _concatUintString(string memory s, uint val) private pure returns(string memory) {
        return string(abi.encodePacked(s, Strings.toString(val)));
    }
}

SwapHandler.sol



컨트랙트 기능 분석

해당 컨트랙트의 취약점을 분석하기 위해서는 2개의 함수를 보아야 합니다.

selfSwap 함수

    function selfSwap(SwapTypes.SelfSwap calldata request) external notPaused {
        //we create a swap request that has no affiliate attached and thus no
        //automatic discount.
        SwapTypes.SwapRequest memory swapReq = SwapTypes.SwapRequest({
            executionRequest: ExecutionTypes.ExecutionRequest({
                fee: ExecutionTypes.FeeDetails({
                    feeToken: request.feeToken,
                    affiliate: address(0),
                    affiliatePortion: 0
                }),
                requester: msg.sender
            }),
            tokenIn: request.tokenIn,
            tokenOut: request.tokenOut,
            routes: request.routes
        });
        SwapMeta memory details = SwapMeta({
            feeIsInput: false,
            isSelfSwap: true,
            startGas: 0,
            preSwapVault: address(DexibleStorage.load().communityVault),
            bpsAmount: 0,
            gasAmount: 0,
            nativeGasAmount: 0,
            toProtocol: 0,
            toRevshare: 0,
            outToTrader: 0,
            preDXBLBalance: 0,
            outAmount: 0,
            inputAmountDue: 0
        });
        details = this.fill(swapReq, details);
        postFill(swapReq, details, true);
    }

selfSwap 함수는 입력한 데이터들을 파싱하여 fill 함수의 인자로 넣어주는 간단한 함수입니다.

fill 함수

    function fill(SwapTypes.SwapRequest calldata request, SwapMeta memory meta) external onlySelf returns (SwapMeta memory)  {

        preCheck(request, meta);
        meta.outAmount = request.tokenOut.token.balanceOf(address(this));

        for(uint i=0;i<request.routes.length;++i) {
            SwapTypes.RouterRequest calldata rr = request.routes[i];
            IERC20(rr.routeAmount.token).safeApprove(rr.spender, rr.routeAmount.amount);
            (bool s, ) = rr.router.call(rr.routerData);

            if(!s) {
                revert("Failed to swap");
            }
        }
        uint out = request.tokenOut.token.balanceOf(address(this));
        if(meta.outAmount < out) {
            meta.outAmount = out - meta.outAmount;
        } else {
            meta.outAmount = 0;
        }

        console.log("Expected", request.tokenOut.amount, "Received", meta.outAmount);
        //first, make sure enough output was generated
        require(meta.outAmount >= request.tokenOut.amount, "Insufficient output generated");
        return meta;
    }

selfSwap 함수에서 파싱한 데이터를 가지고 실제 행위를 수행하는 함수입니다.
onlySelf modifier를 활용하여 selfSwap 함수 등 내부를 통해서만 호출될 수 있도록 하였으며,
preCheck 함수를 통해 request 내 들어있는 토큰의 유효성을 검증합니다.
그 후 router 컨트랙트를 통해 행위를 수행하게 됩니다.



취약점 분석

취약점은 fill 함수에서 rr.router를 검증하지 않아 발생하게 됩니다.

(bool s, ) = rr.router.call(rr.routerData);

이 부분의 인자를 잘 조절하여 아래의 함수호출이 가능하게 됩니다.

// rr.router = token

token.transfrom(victim_address, attacker, amount)

Dexible 컨트랙트의 경우 swapRouter기능도 가지고 있기 때문에, 일반 Dexible에다가 높은 allowance를 걸어놓은 사람이 많고, 해당 공격을 통해 모든 토큰을 탈취할 수 있습니다.
